※ Material loading by vibration disc, convenient and fast.

※ Laser detects front and back, making material selection easy and accurate.

※ Adopting computerized automatic detection, when there are situations such as low air pressure, abnormal motor, or abnormal belt,it can automatically stop and display the cause of the fault, facilitating and quickly resolving the problem.

※ The best feature is simple adjustment, short adjustment time, and can greatly reduce the machine adjustment time.

※ Touchscreen adjusts the compression position, making the compression terminals more precise and stable.

※ It can quickly switch products in a short time.

arameters

Power supply: AC220V/50/60Hz(one phase)

Pressure force:5 - 6 kgf (Requires clean air)

Function:Piercing and crimping

Processing range:2P-20P

Production capacity:3600 PCS/ hour (depending on the product)

Crimping accuracy:±0.01mm

Size:780*740*1400mm(Without protrusions)
